    Zapco - Z-600.2 AP - Class AB, 2-Ch Power 2Ω: 2 x 1000W, 4Ω: 2 x 600W

    Zapco - Z-600.2 AP - Class AB, 2-Ch Power 2Ω: 2 x 1000W, 4Ω: 2 x 600W

    by Zapco
    Sold out
    $2,500.00 - $2,500.00
    $2,500.00
    $2,500.00 - $2,500.00
    $2,500.00

    The Zapco Z-600.2 AP is a Class AB 2-channel amplifier engineered for audiophile sound reproduction and high-current performance. Delivering up to 2000 watts bridged and true 1000 watts per channel at 2 ohms, it offers outstanding clarity, dynamic range, and control. Built with precision-tuned components, advanced thermal management, and Zapco’s signature low-noise design, it’s ideal for powering subwoofers or front-stage systems where SQ meets power.

    • Model: Z-600.2 AP
    • Type: Class AB 2-Channel Full-Range Power Amplifier
    • Power Output (RMS):
     • 4 Ω Stereo: 2 × 600 W
     • 2 Ω Stereo: 2 × 1000 W
     • 4 Ω Bridged: 1 × 2000 W
    • Frequency Response: 10 Hz – 30 kHz (±1 dB)
    • Signal-to-Noise Ratio: > 100 dB
    • THD + N: < 0.05% at rated power
    • Damping Factor: > 200 @ 100 Hz
    • Input Sensitivity: 0.25 V – 8 V (variable)
    • Input Impedance: 20 kΩ (balanced) / 10 kΩ (unbalanced)
    • Crossover Network:
     • High-Pass Filter (HPF): 15 Hz – 4 kHz (12 dB/octave)
     • Low-Pass Filter (LPF): 30 Hz – 4 kHz (12 dB/octave)
     • Band-Pass configuration possible via channel pairing
    • Bass Boost: 0 – 12 dB @ 45 Hz (selectable)
    • Protection Circuits:
     • Thermal overload
     • Short circuit
     • DC offset
     • Over/under voltage
    • Cooling System: Extruded aluminum heatsink with variable-speed fan assist
    • Fuse Rating: 2 × 80 A
    • Power Supply: MOSFET PWM, fully regulated
    • Dimensions: 17.3″ (L) × 8.5″ (W) × 2.5″ (H)
    • Weight: Approx. 13.5 lb (6.1 kg)
    • Included Accessories: Mounting hardware, user manual
