Zapco - HB 84D - Class D, 4-Ch Power 2Ω: 4 x 120W, 4Ω: 4 x 75W

• Model: HB 84D
• Channels: 4 (full-range Class D)
• Power Output:
 • 75 W × 4 @ 4 Ω
 • 120 W × 4 @ 2 Ω
 • Bridged: 240 W × 2 @ 4 Ω
• THD: < 0.5% at rated power
• Signal-to-Noise Ratio: > 95 dB
• Frequency Response: 15 Hz – 30,000 Hz (±1 dB)
• Input Sensitivity: 0.25 V – 6 V (Low level)
• Features:
 • RCA and speaker level inputs
 • Variable input gain control
 • Variable electronic crossover (per channel)
• Dimensions (mm): 160 (L) × 115 (W) × 45 (H)
• Construction: Compact, sealed Class D design
