    Specifications
    Type: Plug-and-Play Extension Cable
    Series: Race Sport Color Smart Rock Light System Components
    Length: 4 ft (48")
    Connector Type: Sealed Weatherproof Plug-and-Play (No Cutting Required)
    Wire Gauge: Multi-Conductor Signal Cable (Matched to OEM Rock Light System)
    Compatibility: Race Sport Color Smart Rock Light Kits (and other Race Sport 4-wire RGB Smart Pods)
    Waterproof Rating: IP67 Weather-Sealed Connector Ends
    Outer Jacket Material: Flexible UV-Stable Protective Sheathing
    Operating Voltage: 12V RGB Control Signal Pass-Through
    Temperature Range: All-Weather / Off-Road Duty Rated

    Key Features
    • True Plug-and-Play – No cutting, splicing, rewiring, or adapter blocks required.
    • 4-Wire Signal Pass-Through – Maintains full RGB color-changing control.
    • Extended Reach – Ideal for long wheelbase setups, UTV frames, lifted trucks, and bagger saddlebag runs.
    • Weather-Sealed Ends – Resistant to mud, water, washdowns, and trail abuse.
    • Flexible Sheathing – Easy routing along frame rails and underbody channels.

    Use Cases
    • Extending wheel-well rock light placement
    • Running from frame to saddlebags on Harley / baggers
    • UTV and SxS long-chassis installs
    • Truck under-body and bed indicator glow systems

    Pro Tip:
    Up to several extensions may be used, but keep total line length balanced across all pods to ensure even brightness and color sync throughout the system.
