Cerwin Vega - XED8001D - 1-Channel / 900W x 1 @ 1Ω RMS, 700W x 1 @ 2Ω RMS

DESCRIPTION

• 1-channel (mono) Class D amplifier

• High-efficiency design for subwoofer systems

• Stable to 1 Ω for maximum output density

FEATURES

• Designed for subwoofer channel applications

• Class D topology for reduced heat and compact footprint

• Low-pass filter, subsonic filter, and gain adjustment for tuning control

• Accepts RCA and high-level (speaker) inputs (OEM radio compatible)

• Protection circuitry: thermal, short, overload, and DC offset

SPECIFICATIONS

• Amplifier Type: Mono Class D

• RMS Power Output (Typical Rated):

  • 900W x 1 @ 1 Ω

  • 700W x 1 @ 2 Ω

  • 400W x 1 @ 4 Ω

• Frequency Response: ~20 Hz – 250 Hz

• Low-Pass Crossover: Variable ~50 Hz – 150 Hz

• Subsonic Filter: ~20 Hz (fixed or selectable, model dependent)

• Signal Inputs: RCA low-level and high-level speaker inputs

• Voltage Requirement: 12V motorcycle / automotive electrical systems

• Efficiency: High-efficiency Class D output stage

• Protection Modes: Thermal / Over-current / Short / Low-impedance safeguard

DIMENSIONS

• Chassis Length: ~10.0 in (254 mm)

• Width: ~6.9 in (175 mm)

• Height: ~1.9 in (48 mm)

• Mounting Profile: Fits fairing amp trays and saddlebag amp racks

FITMENT

• Motorcycle saddlebag amp racks and inner-fairing amplifier bays

• Automotive trunk, hatch, under-seat, and panel mounting

• Works with factory radios when used with LOC or high-level input

INCLUDES

• XED8001D amplifier

• Mounting hardware (varies by package)
