Cerwin Vega - CVBTR6 - Bluetooth Receiver

DESCRIPTION

• Bluetooth® audio receiver module

• Designed to add wireless audio streaming to amplifier-based systems

• Suitable for motorcycle, powersports, marine, and automotive installations

FEATURES

• Provides Bluetooth® streaming directly to amplifier or DSP input

• Stereo output for 2-channel systems (can be used with 4-ch amps using Y-splits)

• Weather-resistant housing designed for outdoor & motorcycle environments

• On-board control buttons for play / pause / skip / volume (model dependent)

• Memory auto-reconnect for fast pairing when powered on

• Works with any smartphone or Bluetooth audio source

SPECIFICATIONS

• Bluetooth Standard: A2DP Wireless Audio Streaming

• Output Type: Low-level stereo RCA (or pigtail signal out depending on batch)

• Power Requirement: 12V Motorcycle / Automotive Electrical

• Signal Range: ~30+ ft typical open-air

• Output Voltage: Preamp-level signal compatible with amplifiers / DSPs

• Noise / Filtering: Built-in ground noise rejection network

• Housing Rating: Weather-resistant for motorcycle & marine duty

DIMENSIONS

• Module Length: ~2.6 in (66 mm)

• Width: ~1.7 in (43 mm)

• Height: ~0.8 in (20 mm)

• Harness Lead Length: ~12–18 in depending on production

• Mount Style: Zip-tie / panel-tape / bracket universal placement

FITMENT

• Motorcycle fairing, inner dash, side panel, or saddlebag amplifier compartment

• Marine & UTV dash / cage mount positions

• Automotive trunk or under-dash AUX add-on systems

• Works standalone (no head unit required)

INCLUDES

• CVBTR6 Bluetooth® Receiver Module

• Wiring pigtail / harness leads

• Installation instructions (simple text format)
