    Zapco - Z-300.2 AP - Class AB, 2-Ch Power 2Ω: 2 x 500W, 4Ω: 2 x 300W

    Zapco - Z-300.2 AP - Class AB, 2-Ch Power 2Ω: 2 x 500W, 4Ω: 2 x 300W

    by Zapco
    $2,083.33 - $2,083.33
    $2,083.33
    $2,083.33 - $2,083.33
    $2,083.33

    The Zapco Z-300.2 AP is a high-end Class AB 2-channel amplifier engineered for exceptional clarity, warmth, and control. Delivering up to 1000 watts bridged or 500 watts per channel at 2 ohms, it’s ideal for powering front stage or subwoofer setups requiring both precision and power. With flexible crossover options, robust protection circuits, and Zapco’s renowned build quality, the Z-300.2 AP offers professional-grade sound performance for serious audio enthusiasts and installers.

    • Model: Z-300.2 AP
    • Type: Class AB 2-Channel Full-Range Power Amplifier
    • Power Output (RMS):
     • 4 Ω Stereo: 2 × 300 W
     • 2 Ω Stereo: 2 × 500 W
     • 4 Ω Bridged: 1 × 1000 W
    • Frequency Response: 10 Hz – 30 kHz (±1 dB)
    • Signal-to-Noise Ratio: > 100 dB
    • THD + N: < 0.05% at rated power
    • Damping Factor: > 200 @ 100 Hz
    • Input Sensitivity: 0.25 V – 8 V (variable)
    • Input Impedance: 20 kΩ (balanced) / 10 kΩ (unbalanced)
    • Crossover Network:
     • High-Pass Filter (HPF): 15 Hz – 4 kHz (12 dB/octave)
     • Low-Pass Filter (LPF): 30 Hz – 4 kHz (12 dB/octave)
     • Band-Pass operation available by combining filters
    • Bass Boost: 0 – 12 dB @ 45 Hz (adjustable)
    • Protection Circuits:
     • Thermal overload
     • Short circuit
     • DC offset
     • Over/under voltage
    • Cooling System: Heavy-duty aluminum heatsink with variable-speed fan assist
    • Fuse Rating: 2 × 60 A
    • Power Supply: Fully regulated MOSFET PWM
    • Dimensions: 17.3″ (L) × 8.5″ (W) × 2.5″ (H)
    • Weight: Approx. 12.8 lb (5.8 kg)
    • Included Accessories: Mounting hardware, user manual
