    Zapco - Z-1100.1 AP - Class AB, Mono Power 2Ω: 1 x 1100W, 4Ω: 1 x 650W

    Zapco - Z-1100.1 AP - Class AB, Mono Power 2Ω: 1 x 1100W, 4Ω: 1 x 650W

    by Zapco
    $2,083.33 - $2,083.33
    $2,083.33
    $2,083.33 - $2,083.33
    $2,083.33

    The Zapco Z-1100.1 AP is a Class AB mono amplifier designed for exceptional clarity, warmth, and dynamic control. Delivering up to 1100 watts RMS at 2 ohms, it’s perfect for high-end subwoofer or full-range applications where pure analog sound quality is paramount. Built with precision-tuned circuitry, robust protection, and Zapco’s renowned craftsmanship, the Z-1100.1 AP ensures accurate, musical power delivery — ideal for audiophile and competition-level installations.

    • Model: Z-1100.1 AP
    • Type: Class AB Mono Full-Range / Subwoofer Amplifier
    • Power Output (RMS):
     • 4 Ω: 1 × 650 W
     • 2 Ω: 1 × 1100 W
    • Frequency Response: 10 Hz – 30 kHz (±1 dB)
    • Signal-to-Noise Ratio: > 100 dB
    • THD + N: < 0.05% at rated power
    • Damping Factor: > 200 @ 100 Hz
    • Input Sensitivity: 0.25 V – 8 V (variable)
    • Input Impedance: 20 kΩ (balanced) / 10 kΩ (unbalanced)
    • Crossover Network:
     • Low-Pass Filter (LPF): 30 Hz – 4 kHz (12 dB/octave)
     • High-Pass Filter (HPF): 15 Hz – 4 kHz (12 dB/octave)
     • Band-pass configuration available through filter combination
    • Bass Boost: 0 – 12 dB @ 45 Hz (adjustable)
    • Cooling System: Oversized aluminum heatsink with smart thermal fan management
    • Protection Circuits:
     • Thermal overload
     • Short circuit
     • DC offset
     • Over/under voltage
    • Fuse Rating: 2 × 60 A
    • Power Supply: Fully regulated MOSFET PWM design
    • Dimensions: 17.3″ (L) × 8.5″ (W) × 2.5″ (H)
    • Weight: Approx. 12.5 lb (5.7 kg)
    • Included Accessories: Remote bass control, mounting hardware, user manual
