Specifications
Type: LED Headlight Conversion Kit (Off-Road Use)
Series: NOVA-LUMEN High-Output Performance Series
Socket Type: 9004 / 9005 (Vehicle Dependent Selection)
Total Light Output: 16,000 Lumens Per Set (8,000 lm Per Bulb)
LED Chip Type: High-Intensity CSP LED Emitters
Color Temperature: 6000K Cool White
Beam Pattern: Optimized Focused Beam w/ Anti-Scatter Cutoff
Voltage Range: 9V – 32V DC
Power Draw: High-Efficiency / Low Current System
Cooling System: Active Thermal Cooling Fan + Aluminum Heat Sink
CANBUS Compatibility: Integrated CANBUS Anti-Flicker / Anti-Error System
Waterproof Rating: IP67 (Weather-Sealed and Washproof)
Housing: CNC-Machined Aircraft Aluminum Body
Lifespan: 30,000+ Hours Rated
Key Features
• True 16,000 Lumen Output – Built for aggressive illumination in off-road environments.
• CANBUS Ready – Reduces flickering, dash errors, and bulb-out warnings in most vehicles.
• Precision Beam Control – Maintains road visibility without excessive glare.
• Dual-Stage Cooling System – Active fan and heat sink for long-term brightness stability.
• Plug-and-Play Installation – No cutting or rewiring in standard applications.
• All-Weather Operation – Protected from mud, dust, water spray, and temperature extremes.
Performance Use Cases
• Off-road trucks
• Jeeps & overlanding rigs
• UTVs and side-by-sides
• Custom motorcycle and ATV headlight retrofits
• Night trail riding and rural road visibility upgrades
Installation Notes
• Plug-and-play fit for most 9004 / 9005 headlight housings.
• If the vehicle uses a headlight auto-sensor / DRL dimming circuit, set CANBUS module behind headlight housing.
• Ensure cooling fans have unrestricted airflow for best performance.
Pro Tip:
Aim headlights after installation. The beam pattern is powerful, so a slight downward adjustment ensures wide forward coverage without blinding oncoming traffic in shared-use environments.
