Specifications
Type: High-Output Midrange Speaker Pair
Series: Diamond Audio MSPRO Series
Size: 8-inch (203mm)
Configuration: Full-Range Pro Audio Midrange Driver
Power Handling (RMS): 500W (Pair) / 250W (Each)
Power Handling (Peak): 1000W (Pair) / 500W (Each)
Impedance: 4Ω
Sensitivity (1W/1m): 100dB
Frequency Response: 100Hz – 9kHz
Voice Coil: 1.5-inch (38mm) High-Temperature Copper
Cone Material: Thermal-Molded Waterproof Paper Cone
Surround: UV-Treated Cloth Accordion Surround
Basket: Heavy-Duty Stamped Steel Frame
Magnet Type: High-Grade Ferrite Motor Structure
Cooling System: Rear-Vented Pole Piece for Thermal Management
Terminals: Nickel-Plated Spring Push Connectors
Mounting Depth: 3.5" (89mm)
Mounting Cutout: 7.3" (185mm)
Overall Diameter: 8.3" (211mm)
Waterproof Rating: IP65 (Marine Grade – Salt, Moisture, and UV Resistant)
Weight: 7.5 lbs (Pair)
Warranty: 1-Year Manufacturer Warranty
Performance Specs
• High-efficiency 8" pro-style midrange engineered for extreme SPL and open-air clarity.
• Thermal-molded waterproof cone ensures durability in all-weather applications.
• Delivers exceptional midbass punch and vocal projection at high volumes.
• Designed for motorcycles, UTVs, boats, and competitive sound builds.
• Compact design allows installation in fairings, towers, or custom enclosures.
Key Features
• Pro-Audio Midrange Design – Optimized for high-output motorcycle and powersport audio.
• 100dB Sensitivity – Extremely efficient, delivering massive output with moderate power.
• Marine-Grade IP65 Construction – Sealed and coated for UV, water, and salt protection.
• Waterproof Paper Cone – Lightweight, rigid, and acoustically natural.
• High-Temp Voice Coil – Handles sustained power without compression.
• Cloth Accordion Surround – Provides smooth midrange extension and transient control.
• Diamond Audio Durability – Built for long-term reliability under extreme conditions.
Performance Integration Notes
• Ideal Pairing: Diamond HXM800.4D or DES400.2D Amplifiers (200–250W RMS per channel).
• System Compatibility: Motorcycle, UTV, Marine, or Open-Air SPL Applications.
• Recommended Use: Front fairing or midbass reinforcement in multi-speaker setups.
• Installation Location: Fairing pods, tower enclosures, or saddlebag baffles.
• Installation Time: Approx. 45–60 minutes.
• Pro Tip: Use a high-pass filter at 90–120Hz (12dB/octave) to reduce cone stress and maintain tight midbass output.
