Specifications
Type: High-Performance Pro Midbass Driver
Speaker Size: 10" (254 mm)
Configuration: Single Voice Coil
Impedance: 4 Ω
RMS Power Handling: 300 W
Peak Power Handling: 600 W
Sensitivity: 97 dB (1W / 1m)
Frequency Response: 50 Hz – 5 kHz
Voice Coil Diameter: 2.5" (63.5 mm)
Voice Coil Material: High-Temperature Copper-Clad Aluminum Wire (CCAW)
Motor Structure: Ultra-Light Neodymium Magnet System (Dual Stack)
Cone Material: Carbon Matrix Composite with Structural Resin Core
Surround: Low-Mass Cloth Surround (Damped for SPL Stability)
Basket: Cast Aluminum – CNC Venting for Cooling
Spider: Dual Progressive Nomex Suspension
Mounting Depth: 4.5" (114 mm)
Cutout Diameter: 9.25" (235 mm)
Warranty: 2-Year Manufacturer Warranty
Audio Performance Specs
• Frequency Range: 50 Hz – 5 kHz (Optimized for Midbass Power & Detail)
• Sensitivity: 97 dB – High efficiency for extreme motorcycle SPL applications.
• Power Handling: 300 W RMS continuous power for sustained clarity and punch.
• Cone Composition: Carbon Matrix composite delivers stiffness, precision, and low distortion.
• Motor Design: Neodymium motor dramatically reduces weight while increasing control and transient speed.
• Cooling Efficiency: CNC-vented basket and open pole design keep the voice coil cool under high load.
Key Features
• Lightweight Neodymium Motor Structure – Provides maximum magnetic strength in a compact, lightweight design ideal for motorcycle and powersports installs.
• Carbon Matrix Cone Technology – Ultra-rigid, ultra-light cone for superior midbass accuracy and transient response.
• High-Efficiency SPL Output – Engineered to deliver hard-hitting midbass in open-air Harley® and UTV environments.
• Pro-Grade Durability – Designed for long-term reliability under vibration, heat, and constant sound pressure.
• Advanced Cooling System – CNC-vented basket and motor venting ensure consistent thermal performance.
• Optimized Suspension System – Dual progressive spiders provide linear excursion and control at high volume.
• Cicada Audio Signature Sound – Powerful, musical, and aggressive midbass designed and tested in the USA.
Performance Integration Notes
• Recommended Amplifier Pairing: Cicada FLX2500.1 / CX250.2D / DSP125.4D
• System Configuration: Designed for Harley-Davidson® bag-mounted midbass systems (with 24HDRING10 / HDPORT3).
• Crossover Settings: HPF at 60–70 Hz / LPF at 5 kHz (24 dB/octave recommended).
• Installation Time: Approx. 45–60 minutes (Professional Installation Recommended).
• Pro Tip: Combine with Cicada RR075T or RR1T tweeters for complete, high-efficiency front or rear stage balance.
