Specifications
Type: High-Performance Waterproof Full-Range Coaxial Horn Speaker
Series: Motorsport NEO Series
Size: 6x9-inch (Oval Frame)
Impedance: 4Ω
Power Handling (RMS): 400W
Power Handling (Peak): 800W
Sensitivity (1W/1m): 97dB
Frequency Response: 80Hz – 22kHz
Cone Material: Carbon-Fiber Reinforced Poly Matrix
Surround: UV-Treated Rubber
Voice Coil: 2-inch High-Temperature Copper on Kapton Former
Tweeter Type: Integrated Compression Horn Driver
Tweeter Diaphragm: Titanium Dome
Magnet Structure: Neodymium Motor Assembly (Lightweight High-Flux Design)
Frame: High-Strength Glass-Filled Composite Basket
Crossover: Built-In 12dB High-Pass Network
Waterproof Rating: IP65 – Marine and Powersport Certified
Mounting Depth: 3.35" (85mm)
Mounting Cutout: 8.7" x 5.9" (221mm x 150mm)
Weight: 4.2 lbs (Each)
Warranty: 2-Year Manufacturer Warranty
Performance Specs
• Delivers concert-level sound clarity and projection for motorcycles, boats, and powersport vehicles.
• Neodymium motor design maximizes SPL output while minimizing overall speaker weight.
• Integrated titanium compression horn produces precise, extended high frequencies.
• Carbon-fiber cone maintains rigidity for accurate midbass even under high power.
• Fully waterproof and UV-protected construction for long-term outdoor reliability.
Key Features
• Full-Range Coaxial Horn – Combines high-efficiency horn tweeter and midbass driver in one compact unit.
• Neodymium Magnet Assembly – Lightweight, powerful motor for maximum output per watt.
• Carbon-Fiber Cone – Weatherproof and acoustically inert for clean midrange response.
• Integrated Titanium Tweeter – Delivers bright, detailed highs with controlled dispersion.
• Motorsport-Grade Durability – Designed to handle extreme vibration, heat, and moisture.
• Built-In Crossover Network – Optimized for seamless full-range frequency integration.
• Diamond Audio Craftsmanship – Tuned for accuracy, projection, and long-term performance.
Performance Integration Notes
• Ideal Pairing: Diamond HXM800.4D, HXM1500.2D, or other 4Ω-stable Motorsport amplifiers.
• System Compatibility: Harley-Davidson®, Marine, UTV, and Custom Powersport Systems.
• Recommended Use: High-output full-range driver for open-air and outdoor installations.
• Installation Location: Bag lids, fairings, doors, or marine enclosures.
• Installation Time: Approx. 45–60 minutes per pair.
• Pro Tip: Use a high-pass filter at 80Hz @ 12dB/oct for maximum performance and speaker protection.
