Specifications
Type: High-Performance Coaxial Speaker
Speaker Size: 6.5" (165 mm)
Impedance: 2 Ω
RMS Power Handling: 125 W
Peak Power Handling: 250 W
Sensitivity: 95 dB (1 W / 1 m)
Frequency Response: 60 Hz – 18 kHz
Cone Material: Carbon Matrix Reinforced Pulp Composite
Tweeter Type: Integrated Dome Tweeter
Tweeter Material: Titanium
Voice Coil Diameter: 1.5" High-Temperature Copper
Magnet Structure: High-Energy Ferrite Motor
Basket: Heavy-Duty Stamped Steel Frame
Surround: UV-Stable Rubber Surround
Mounting Depth: 2.85" (72 mm)
Weather Resistance: UV, Moisture, and Vibration Resistant
Sold As: Pair (Left & Right Speakers)
Warranty: 2-Year Manufacturer Warranty
Audio Performance Specs
• Frequency Range: 60 Hz – 18 kHz – Balanced sound reproduction with solid midbass and crisp highs.
• Sensitivity: 95 dB – Optimized for high SPL and open-air efficiency.
• 2-Ohm Impedance: Draws maximum power from high-current amplifiers.
• Fast Transient Response: Delivers dynamic clarity and punch, even at high volume.
• Sound Profile: Smooth midrange with tight, responsive bass and clean upper extension.
Key Features
• Purpose-Built for Harley-Davidson® Touring and Powersport Applications – Engineered for clarity, projection, and efficiency.
• Carbon Matrix Cone Technology – Combines stiffness and lightness for tight, musical midbass performance.
• Titanium Tweeter Design – Provides sparkling detail and smooth, high-frequency extension.
• 2-Ohm Configuration – Ideal for pairing with high-current multi-channel amplifiers.
• Weatherproof Construction – Built to withstand UV, moisture, and vibration for extreme outdoor conditions.
• High-Energy Motor Design – Delivers dynamic headroom and low distortion at any listening level.
• Cicada Audio Engineering – Tuned and tested in the USA for pro-level sound quality on the road.
Performance Integration Notes
• Recommended Amplifiers: Cicada DSP125.4D / DSP150.4D / CX150.4D / FLX250.4D.
• System Fit: Harley-Davidson® Fairings, Lowers, or Custom Enclosures.
• Crossover Settings: HPF 60–70 Hz / LPF 17–18 kHz (24 dB/Octave).
• Compatible Grilles: Cicada CBG65FR / CBG65LR / CBG65MT (Billet and Flush Variants).
• Installation Time: Approx. 45 minutes (Professional Installation Recommended).
